Lindy 300m Cat.6 4 Port VGA Splitter Extender Transmitter
- Extends 4 x VGA signals simultaneously up to 300m with standard network cables
- Combine with the compatible receiver (35404) to create a 4-zone extension solution
- Supports resolutions up to 1920x1080, with dual mono audio embedding
- Local VGA loop-out connection with dual mono audio extraction
- 2 Year Warranty
Secure Payments
Secure payment methods
Shipping Policy
Free Delivery On Standard UK Mainland Orders **Over £500
Returns Policy
Returns and exchanges
VGA splitter extenders distribute analogue video content across longer distances into multiple locations, using standard network cabling.
The Lindy 300m Cat.6 4 Port VGA Splitter is a high-quality solution for extending 4 separate analogue VGA signals over long distances using standard network cables when combined with the compatible receiver unit (35404). Supporting resolutions up to 1920x1080, this extender splitter provides high quality video for up to 4 separate distribution zones, such as classrooms or in security facilities. A 3.5mm female port ensures source devices or embedded audio can be added within the connection.
The VGA loop-out allows for the connection of a local display, great for monitoring and control of the setup. Dual mono audio extraction also provides the possibility of connecting speakers to the local setup.
The transmitter has a robust metal housing with mounting brackets, providing additional protection against accidental damage, ideal for use in industrial installations.
Lindy 300m Cat.6 4 Port VGA Splitter Extender Transmitter. Type: AV transmitter, Maximum resolution: 1920 x 1080 pixels, Cable types supported: Cat5e, Cat6. Connectivity technology: Wired. Operating voltage: 12 V, Input current: 1.2 A. Width: 135.4 mm, Depth: 73 mm, Height: 31 mm. Quantity per pack: 1 pc(s), Package width: 177 mm, Package depth: 75 mm
The Lindy 300m Cat.6 4 Port VGA Splitter is a high-quality solution for extending 4 separate analogue VGA signals over long distances using standard network cables when combined with the compatible receiver unit (35404). Supporting resolutions up to 1920x1080, this extender splitter provides high quality video for up to 4 separate distribution zones, such as classrooms or in security facilities. A 3.5mm female port ensures source devices or embedded audio can be added within the connection.
The VGA loop-out allows for the connection of a local display, great for monitoring and control of the setup. Dual mono audio extraction also provides the possibility of connecting speakers to the local setup.
The transmitter has a robust metal housing with mounting brackets, providing additional protection against accidental damage, ideal for use in industrial installations.
Lindy 300m Cat.6 4 Port VGA Splitter Extender Transmitter. Type: AV transmitter, Maximum resolution: 1920 x 1080 pixels, Cable types supported: Cat5e, Cat6. Connectivity technology: Wired. Operating voltage: 12 V, Input current: 1.2 A. Width: 135.4 mm, Depth: 73 mm, Height: 31 mm. Quantity per pack: 1 pc(s), Package width: 177 mm, Package depth: 75 mm
| Features | |
| Type | AV transmitter |
| Maximum resolution | 1920 x 1080 pixels |
| Cable types supported | Cat5e, Cat6 |
| Chipset | EL4543IUZ |
| Material | Metal |
| Product colour | Black |
| Certification | CE, FCC, RoHS, REACH |
| Ports & interfaces | |
| Connectivity technology | Wired |
| RJ-45 output ports | 4 |
| VGA (D-Sub) output ports | 1 |
| Audio output | 1 |
| DC-in jack | Yes |
| Power | |
| Operating voltage | 12 V |
| Input current | 1.2 A |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 80% |
| Weight & dimensions | |
| Width | 135.4 mm |
| Depth | 73 mm |
| Height | 31 mm |
| Weight | 484 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 177 mm |
| Package depth | 75 mm |
| Package height | 110 mm |
| Package weight | 547 g |
35403
22 Items
Data sheet
- Product colour
- Black
- Quantity per pack
- 1 pc(s)
- Maximum resolution
- 1920 x 1080 pixels
- Material
- Metal
- Connectivity technology
- Wired
- Type
- AV transmitter
- Maximum transfer distance
- 300 m
- Certification
- CE, FCC, RoHS, REACH
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -20 - 70 °C
- Width
- 135.4 mm
- Depth
- 73 mm
- Height
- 31 mm
- Weight
- 484 g
- Package width
- 177 mm
- Package depth
- 75 mm
- Package weight
- 547 g
- Operating relative humidity (H-H)
- 20 - 80%
- Package height
- 110 mm
- Cable types supported
- Cat5e, Cat6
- Input current
- 1.2 A
- Chipset
- EL4543IUZ
- Audio input
- 1
- Audio output
- 1
- Supported graphics resolutions
- 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1920 x 1080 (HD 1080)
- Bandwidth
- 350 MHz
- RJ-45 output ports
- 4
- VGA (D-Sub) input ports
- 1
- VGA (D-Sub) output ports
- 1
- DC-in jack
- Yes
- Operating voltage
- 12 V
Specific References
- EAN13
- 4002888354035
- MPN
- 35403
