The Lindy 4 Port HDMI® 8K Switch with eARC is a professional solution for providing simple yet reliable switching control over 4 HDMI® source devices connected to a single HDMI® display, while also expanding a displays HDMI® port connections. Supporting HDMI® 2.1 48G signals, this switch allows for the transmission of detailed 8K resolutions, while additional support for High-Dynamic Range ensures video content can be seen with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for a premium home cinema experience, eye-catching digital signage in retail settings or engaging presentations. HDCP 2.3 support ensures there are no issues with a variety of 8K content when connected to source devices including set top boxes, Blu-Ray players and 8K HDR media players.

As well as HDMI® audio pass-through, the switches 3.5mm audio port allows for a separate connection of both analogue speaker systems, and optical audio devices such as soundbars and amplifiers, great for ensuring a multi-channel audio experience to provide a heightened sense of realism for the viewer.

The Switch also supports eARC (Enhanced Audio Return Channel), enabling high-quality audio formats like Dolby Atmos and DTS:X to be transmitted directly to compatible audio devices. This simplifies setups by using the HDMI® cable for audio, reducing extra cables and enhancing the immersive audio experience, perfect for high-end home theater systems.

This 4 Port HDMI® switch also provides a huge range of seamless control options for the user, to ensure efficient, hassle free usage for both new, and experienced users. The switch itself can be controlled manually via push button switching, while it can also identify the active HDMI® source device and automatically switch to this option.

The included remote control allows the user to have convenient control over multiple videos and audio formats from a distance, great for trade show demonstrations or training presentations.

Lindy 4 Port HDMI 8K60 Switch with eARC. Video port type: HDMI, Console ports: HDMI, USB A, USB C. HD type: 8K Ultra HD, Maximum resolution: 7680 x 4320 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Metal, LED indicators: Status. Power source: DC, Input voltage: 5 V, Output current: 1 A. Compliance certificates: CE, Federal Communications Commission (FCC), REACH, RoHS

Ports & interfaces
Number of computers controlled	4
Video port type	HDMI
HDMI version	2.1
Console ports	HDMI, USB A, USB C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity	1
DC-in jack	Yes
Performance
HD type	8K Ultra HD
Maximum resolution	7680 x 4320 pixels
Video bandwidth	60 Hz
Data transfer rate (max)	48 Gbit/s
HDCP	Yes
HDCP version	2.3
Design
Rack mounting	No
Product colour	Black
Housing material	Metal
LED indicators	Status
Push button	Yes
Hot keys	Yes
Certification	CE, FCC, RoHS & REACH
Display
Built-in display	No
Power
Power source	DC
Input voltage	5 V
Output current	1 A
Sustainability
Compliance certificates	CE, Federal Communications Commission (FCC), REACH, RoHS
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 90%
Weight & dimensions
Width	176 mm
Depth	18 mm
Height	68 mm
Weight	311 g
Packaging data
Package width	240 mm
Package depth	130 mm
Package height	70 mm
Package weight	540 g
Package type	Box
Packaging content
Cables included	DC, HDMI, USB Type-A to Micro USB-B
Remote control included	Yes
Other features
Warranty period	2 year(s)
