Lindy 2 Port HDMI 8K60 Splitter with Audio
- Displays HDMI signals across 2 displays simultaneously from one source device
- Supports resolutions up to 8K 60Hz 4:4:4, with additional support for HDR
- Extract digital and analogue audio from HDMI for non-HDMI amplifiers
- Features a neat switch for downscaling from 8K to 4K or 1080p
- 2 Year Warranty
Secure Payments
Secure payment methods
Shipping Policy
Free Delivery On Standard UK Mainland Orders **Over £500
Returns Policy
Returns and exchanges
The Lindy 2 Port HDMI® 8K60 Splitter with Audio is a multi-function solution for distributing high quality HDMI® signals across 2 displays simultaneously from one source device, while extracting digital or analogue audio separately.
With support for resolutions up to 8K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching dual display digital signage in retail scenarios, displaying live video across two screens at event venues or distributing engaging multiscreen educational presentations at tradeshows.
The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI® to connect non-HDMI® amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.
The splitters also features an integrated switch to downscale the input signal to 4K or Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.
Lindy 2 Port HDMI 8K60 Splitter with Audio. Video port type: HDMI, Video out: 2x HDMI, Headphone connectivity: 3.5 mm. Maximum resolution: 7680 x 4320 pixels, Product colour: Black, Housing material: Metal. AC input voltage: 5 V, Input current: 2 A. Width: 145 mm, Depth: 17 mm, Height: 68 mm. Quantity per pack: 1 pc(s), Package width: 200 mm, Package depth: 70 mm
With support for resolutions up to 8K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching dual display digital signage in retail scenarios, displaying live video across two screens at event venues or distributing engaging multiscreen educational presentations at tradeshows.
The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI® to connect non-HDMI® amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.
The splitters also features an integrated switch to downscale the input signal to 4K or Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.
Lindy 2 Port HDMI 8K60 Splitter with Audio. Video port type: HDMI, Video out: 2x HDMI, Headphone connectivity: 3.5 mm. Maximum resolution: 7680 x 4320 pixels, Product colour: Black, Housing material: Metal. AC input voltage: 5 V, Input current: 2 A. Width: 145 mm, Depth: 17 mm, Height: 68 mm. Quantity per pack: 1 pc(s), Package width: 200 mm, Package depth: 70 mm
| Ports & interfaces | |
| Video ports quantity | 2 |
| Video port type | HDMI |
| Video out | 2x HDMI |
| HDMI version | 2.1 |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
| Features | |
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 7680 x 4320 pixels |
| HD type | 8K Ultra HD |
| Colour depth | 8 bit |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.3 |
| Data transfer rate | 48 Gbit/s |
| HDCP | Yes |
| LED indicators | Yes |
| Certification | CE, FCC, RoHS, REACH & California Proposition 65 |
| Power | |
| AC input voltage | 5 V |
| Input current | 2 A |
| Weight & dimensions | |
| Width | 145 mm |
| Depth | 17 mm |
| Height | 68 mm |
| Weight | 325 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 200 mm |
| Package depth | 70 mm |
| Package height | 115 mm |
| Package weight | 458 g |
| Package type | Box |
| Packaging content | |
| Included power plug types | AU, EU, UK |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 20 - 90% |
38534
1 Item
Data sheet
- Connector 1
- 2 x HDMI Type A
- Connector 2
- HDMI Type A
- Product colour
- Black
- Quantity per pack
- 1 pc(s)
- Video port type
- HDMI
- HD type
- 8K Ultra HD
- Maximum resolution
- 7680 x 4320 pixels
- Data transfer rate
- 48 Gbit/s
- Housing material
- Metal
- Certification
- CE, FCC, RoHS, REACH & California Proposition 65
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Width
- 145 mm
- Depth
- 17 mm
- Height
- 68 mm
- Weight
- 325 g
- Package width
- 200 mm
- Package depth
- 70 mm
- Package weight
- 458 g
- Package type
- Box
- LED indicators
- Yes
- Manual
- Yes
- Package height
- 115 mm
- AC adapter included
- Yes
- Compliance certificates
- CE, Federal Communications Commission (FCC), REACH, RoHS
- Warranty period
- 2 year(s)
- Input current
- 2 A
- Cables included
- Power
- Storage relative humidity (H-H)
- 20 - 90%
- AC input voltage
- 5 V
- Included power plug types
- AU, EU, UK
- DC-in jack
- Yes
- Video ports quantity
- 2
- Video out
- 2x HDMI
- HDMI version
- 2.1
- HDCP
- Yes
- Maximum refresh rate
- 60 Hz
- Colour depth
- 8 bit
- HDCP version
- 2.3
- Digital audio optical out
- 1
- Headphone out
- Yes
- Headphone connectivity
- 3.5 mm
- Easy to install
- Yes
Specific References
- EAN13
- 4002888385343
- MPN
- 38534
